Connection type:

BMT

Tool holder type:

axial drilling and milling head

Tool connection:

ER25

Tool height:

H55

Machine connection code:

02717 (BMT45 L76)

Cooling type:

internal cooling

Gear ratio:

i=1:1

Rotation max:

6000 1/min

Pressure max:

25 bar

Torque max:

50 Nm

Goodway:

GLS-150, 200 M/Y (DIN1809 version)

GLS-1500, 2000 M/LY/LMS/LYS

GTS-150 MMX/XY (new turret version)

GTW-1500

Miyano:

ABX 51, 64 SY/TH2/TH3

BND-51 C/S/SY

BNE-34,51 S/SY/MSY

BNE-51,65 MYY

BNJ 34,42,51 S/SY

BNX 42,51 SY
